Hello all,

I’ve got a 2006 Haas VF1 SS (15k rpm). It runs great but there is one repetative issue that I cannot figure out.
My post calls for the next operation’s tool immediately after it changes from the previous operation tool to the current operation tool. Such as: The program is started, carousel moves to operation 1 tool, it is loaded into spindle, the next command calls for carousel to move to op2 tool, and then it continues on with operation 1. when op1 ends, op2 tool is already positioned and can be swapped immediately. once op2 tool is in the spindle, the carousel moves to op3 tool and waits while the op2 runs. and so on…

Sometimes, at the end of an operation, it throws the 626 error: Tool Pocket Slide Error. What I have figured out is, the error will subsequently be thrown if the carousel, for whatever reason, ignores the «next operation tool» request at the beginning of the current operation. I’m not sure if it ignores it (as it’s just doing what it’s told) or the error is actually thrown at that point in time and does not present on the screen until the end of the current operation…

This is a snippet of a program that consistently throws the error when the 4th operation (N4) ends and it’s supposed to get the tool for the 5th operation (N5, T7). When op3 starts, the machine spindles op 3 tool from the carousel, then moves the carousel to op4 tool, and starts the actual op3. When op3 is done the machine swaps op3 tool for op4 tool and starts op4. Prioir to starting the actual operation 4, the carousel is supposed to move to op5 tool, but it does not. Once op4 is complete (or almost complete), the spindle shuts off and the error code is thrown. sometimes when the error is thrown the current line of code is not quite at the end of the operation, it can be 10-50 lines from the end. So I hit reset, find N5 in the program and hit start, it swaps the tool and runs operation 5.

I suspect it has to do with some timing issue in the parameters such as 62, 306, etc. I’ve attached a pic of my current parameter settings having to do with the carousel and tool changing. I’m not sure if there’s one that’s just radiccially wrong and causing this issue.

%
O1000 (NHC OP1_MILLING)
N100 (COMPENSATION-WEAR)
N102 (REV-0.70)
N104 (JUL-14-2021-5:48:13PM)

N106 (TOOL 3 — DIA 12.7)
N108 (TOOL 4 — DIA 4.762)
N110 (T5-COBALT/ChipClearing — 6.7564mm)
N112 (TOOL 6 — DIA 3.175)
N114 (T7-COBALT/ChipClearing — 1mm)

N1 G90 G17 G40 G80 G00
N116 M06 T3 ()
N118 T4
N120 (iRough-contour7)
N122 S4693 M03
……….(operation code using T3 removed)
N15412 M01

N2 G90 G17 G40 G80 G00
N15414 M06 T4 ()
N15416 T5
N15418 (iRest-contour2-1)
N15420 S8961 M03
……….(operation code using T4 removed)
N16188 M01

N3 G90 G17 G40 G80 G00
N16190 M06 T5 (COBALT/ChipClearing — 6.7564mm)
N16192 T6
N16194 (D-drill)
N16196 S453 M03
……….(operation code using T5 removed)
N16208 M01

N4 G90 G17 G40 G80 G00
N16210 M06 T6 ()
N16212 T7……..(I have witnessed the T6 tool change and then the carousel NOT moving to T7 for whatever reason)
N16214 (iRough-contour6)
N16216 S10778 M03
……….(operation code using T6 removed)
N16714 M01

….THIS IS WHERE ERROR IS THROWN….

N5 G90 G17 G40 G80 G00
N16716 M06 T7 (COBALT/ChipClearing — 1mm)
N16718 (D-drill1)
N16720 S3500 M03
……….(operation code using T7 removed)
N16744 M06 T3
N16746 M30
%
